RAM 302
RAMSET
www.ramsetinc.com 19
BiLL OF mATEriALS FOr: rAm 302
iTEm pArT # pArT dESCripTiON rAm 302
1 800-00-30 Chassis Base 1
2 800-02-09 Gear Reducer—Size 70, Ratio 900:1 1
3 800-04-10 Motor, Standard—120VAC 1/2 HP 1
4 800-08-25 Pulley, Steel—1/2” x 2 1/2” (AK25) 1
5 800-08-40 Pulley, Steel— 5/8” x 2 1/2” (AK25) 1
6 800-10-05 Belt—4L-170 1
7 800-14-06 Cover, Polyethylene 1
8 800-14-15 Cover, Polyethylene Cap Arm 1
9 800-14-21 Cover, Metal Control Board 1
10 800-20-05 Limit Switch - Swing Operator 2
11 800-28-26 Pivot—2 1/2” x 3 1/4” (1” shaft) 1
12 800-48-01 Cam, Limit Switch—1 3/8” 2
13 800-54-51 Bracket, Mounting—Limit Switch 1
14 800-54-65 Bracket, Mounting—Receiver 1
15 800-54-70 Bracket, Outlet 1
16 800-56-01 Box, Control Board Metal 1
17 800-60-00 Transformer, 120/240V to 18VAC - 40VA UL 1
18 800-60-10 Switch, Rocker 1
19 800-60-21 Outlet, Single Square 1
20 800-62-00 Control Board—Intelligate 1
21 800-64-00 Edge Connector—20 Pin 1
22 800-68-06 Instruction Manual 1
23 800-70-20 Horn Alarm Buzzer 1
24 800-70-26 Hub, Limit Switch Cam 1
25 800-70-36 Knob—5/16” - 18 x 1/2” 1
26 800-70-55 Radio Receiver Terminal 1
27 800-70-99 Warning Sign For Gates 2
28 800-75-50 CLAmp rELEASE ASSEmBLy 1
29 800-28-35 Release, lever handle—5/8” - 11 x 1 3/4” 1
30 800-50-00 Clamp, Release—Back 1
31 800-50-01 Clamp, Release—Front 1
32 800-54-20 Bracket, Clamp Arm 1
33 800-75-00 Arm ASSEmBLy (iNCLudES hArdwArE) 1
34 800-28-00 Arm, Metal Tubing—1” x 2” x 32” 1
35 800-28-01 Arm, Metal Tubing —1” x 2” x 42” 1
36 800-54-10 Bracket, Channel —1 3/4” x 10” 1
37 800-54-30 Bracket, External Gate —1 1/2” x 12” 1
38 800-54-37 Bracket, Gate 1
