RAM 50 GB
7
RAMSET
www.ramsetinc.com
FRONT INSTALLATION
GATE SHOWN Closed
Tail on gate required
TAIL WALL
7”
CENTER INSTALLATION
GATE SHOWN Fully Open
Tail on gate required
REAR INSTALLATION GATE SHOWN
Fully Open
Tail on gate required
Front View
Front View
Top View
Top View
Hidden Wall
7”
10 1/2”
USE ONLY CHAIN
GUARDED PULLEYS
WARNING:
USE ONLY CHAIN
GUARDED PULLEYS
WARNING:
TYPES OF INSTALLATIONS
Figure 4
Figure 5
Figure 6
Inside
Property
Inside
Property
Inside
Property
Outside
Property
Outside
Property
Outside
Property
