RAM 50 GB
5
RAMSET
www.ramsetinc.com
GENERAL SPECIFICATIONS
EMERGENCY ChAIN RELEASE
WARNING
Do not exceed the specifications. The warranty on your unit will be void if the
installation exceeds the recommended specifications.
MAXIMUM GATE SIZE & WEIGhT: 20’ @ 700 lbs
GATE TRAvELING SPEED: Approx 1' per sec
MOTOR: 1/2 Hp, 120 VAC, 5.2 amp, 50/60Hz
DUTY CYCLE: 30 Cycles/ Hr
OPERATING TEMPERATURE: -10º F to 160º F
POWER FAILURE RELEASE: Chain Release
OvERALL DIMENSIONS: H 16½” L 11” W 17”
ShIPPING WEIGhT: 75 lbs
Remove the lock from the
chain release and open the
gate manually
