Ram 50 gb, Bill of materials – Controlled Products Systems Group RAM-50GB User Manual
Page 19
RAM 50 GB
17
RAMSET
www.ramsetinc.com
BILL OF MATERIALS
ITEM
PART #
PART DESCRIPTION
QTY
1
800-00-40
Chassis
1
2
800-00-45
Shelf, Lower GR/Motor
1
3
800-00-46
Shelf, Upper PCB
1
4
800-02-15
Gear Reducer - Size 40, Ratio 30:1
1
5
800-04-11
Motor, Standard - 120VAC 1/2 HP
1
6
800-04-91
Capacitor, Motor - 60uF @ 250VAC
1
7
800-06-13
Sprocket - 41-20 x 5/8"
1
8
800-08-22
Pulley, Steel - 1/2" x 2"
1
9
800-08-27
Pulley, Steel - 1/2" x 3"
1
10
800-10-05
Belt - 4L-170
1
11
800-14-10
Cover, Metal
1
12
800-20-05
Limit Switch
2
13
800-20-50
Limit Switch Nuts
2
14
800-22-04
Spring - 1/4" x 1/2"
2
15
800-52-02
Chain - #41 (10ft per box)
2
16
800-52-30
Chain Bolt - 1/2" - 13 x 3 1/4"
2
17
800-52-35
Chain Bolt Coupler
1
18
800-52-36
Chain Bolt Release
1
19
800-54-15
Bracket, Chain (Left) - 3/8" x 2" x 2" x 3 1/4"
1
20
800-54-16
Bracket, Chain (Right) - 3/8" x 2" x 2" x 3 1/4"
1
21
800-54-44
Bracket, Limit Switch
1
22
800-54-79
Bracket, Spring Loaded - 5 1/2"
1
23
800-54-90
Base, Limit Switch Assembly
1
24
800-60-00
Transformer, 120/240V to 18VAC - 40VA UL
1
25
800-60-10
Switch, Rocker
1
26
800-60-21
Outlet, Single Square
1
27
800-62-00
Control Board - Intelligate
1
28
800-64-00
Edge Connector - 20 Pin
1
29
800-66-06
Lexan Control Board Cover
1
30
800-68-09
Instruction Manual
1
31
800-70-18
Guard, Sprocket
1
32
800-70-20
Horn Alarm Buzzer
1
33
800-70-54
Plate, Chassis Support - H: 3" x W: 13" x D: 3/16"
1
34
800-70-55
Radio Receiver Terminal
1
35
800-70-99
Warning Sign For Gates
2
36
800-75-28
Idler Wheel Assembly - Ram 50
1
37
800-36-63
Bolt, Hex Head - 5/8" - 11 x 3"
2
38
800-70-30
Idler Wheel, UHMW - 2 1/2" x 1 1/4" - I.D. 5/8"
2
