Controlled Products Systems Group OH200DC - Manual (Page 13)

12
C C
Power Power
Detect Detect
Loop Fail Loop Fail
Reset Reset
2 2
1 1
0 0 0 0
SENS. SENS.
LEVEL LEVEL
BOOST ON BOOST ON
PULSE PULSE
FREQ. FREQ.
0 0
0 0
OFF OFF
PRES PRES
2 2 1 1
11
22
33
44 55
66
SAFETY Loop
Detector
PHOTO Beam
EXIT
Loop
Detector
Keypad
or
Telephone
Push Button
or
Fire Box
Card Reader
or
Key Switch
See page 12 for connection of
multiple safety device wiring
diagram.
See page 14 for plugin loop
detector installation.
Remove wire jumper
from when
a safety device is
installed.
SAFETY
ACCESSORY CONNECTIONS
AB
= NORMALLY OPEN CONTACT
N/C
= NORMALLY CLOSED CONTACT
C
= COMMON
N/C
N/O
The circuit board output provides up to mAmps of power for accessories. More
than two or three accessories will require a separate power supply.
12VDC Accessories only.
12-VDC 500
NOTE:
