RECEIVER OPTIONS
Do not confuse the receiver code switches with the red program switches on the gate control board.
Never set all code switches to the same position. Transmitters must match code switches for proper operation.
If power is taken directly from battery or connected as shown below, receiver should be configured for 12VDC
Multi-Code/Digi-Code
Allstar
Lift-Master
black
gray
gray
red
white
black
red
4
3
2
1
Heddolf
black
yellow
red
white
Jumpers must be
set for 12V &
constant relay
option
