Controlled Products Systems Group NT-T5-ETLDUAL User Manual
Page 16
16
16
LED Enable & Learn
Mode Push Button
Optional Device Inputs
Stop Circuit Jumper
Fire & ETL Inputs
Emergency Bypass
Reverse Battery Polarity
Indicators
Optional Device Input
Remote Monitor Outputs
Microprocessor
Timer To Close -
Dual Gate Delay -
Current Sensitivity -
Adjustments
Program Switches
835/836 Control Board Parts Identification
Operator Connector
(Master)
Operator Connector
(Slave)
Control Board Reset
Hard Shutdown Reset
Operate Push Button
