LRA Linear Residential Actuator Installation Guide
- 23 -
228158 Revision X17 8-11-2011
Gate Operation
Open Button
Opens the gate. If the Controller is programmed to stop opening the
gate at mid-travel, a constant press of the OPEN button will override the
Mid-travel Stop and completely open the gate. If the Auto Close Timer is
set, it will be suspended until the OPEN button is released.
Close Button
Closes the gate if the gate is open. Also closes the gate if the gate is in
the process of opening.
Stop Button
Stops the gate from opening or closing at any time.
Single Input
Opens the gate if it’s closed and closes the gate if it’s open (open-close
programming option). Activating the input while the gate is moving will
reverse the gate.
Can be programmed to stop the gate while the gate is moving (open-
stop-close programming option).
Fire Department Input
Fully opens the gate when the input is activated. Overrides the Mid-travel
Stop and Auto Close Timer (if either is programmed for the gate). The
gate will lockout in the open position without sounding the alarm. Press
the STOP button to release the lockout.
Open Input
Functions the same as the OPEN button.
Open Obstruction
While the gate opening, any open obstruction signal will cause the gate
to stop, reverse a short distance, and then stop again. The Auto Close
Timer will be disabled, and a renewed input will be required to start the
gate again. Should the gate be restarted and the obstacle signal occur
again prior to reaching a limit, the gate will stop again, lockout, and sound
the emergency alarm.
Close Obstruction
Same as the open obstruction, but in the closing direction.
Reverse Input
If the reverse input is triggered while the gate is closing, the gate will
reverse to the full open position. If the Auto Close Timer is set, when the
reverse input is cleared, the gate will close when the Auto Close Timer
expires.
Open Loop
Functions the same as the OPEN button.
Reverse Loop
Functions the same as the reverse input.
Shadow/Reset Loop
Holds the gate fully open or fully closed while triggered. If open, the gate
closes immediately when cleared if Anti-tailgate is enabled.
Operation Indications
During normal operation, the Controller’s displays will
indicate current operating conditions and status.
Power-up Display
When the Controller powers up, dashes will show on the
display, then the fi rmware version number, then the gate
type (SL for slide and swing gates).
Exiting programming restarts the Controller. The power-up
display will show upon the restart.
Idle Condition
While the Controller is idling, waiting for a command, the
display will show circulating dashes.
For DC models only - Clockwise : Batteries discharging,
Counterclockwise : Batteries charging
Last Gate Position/Condition
When the gate moves or stops, the display will show the
status for up to one minute.
• Stop is displayed as
St
• Full Close is displayed as
FC
• Full Open is displayed as
FO
• Entrapment is displayed as
En
Pre-start Delay
During the pre-start delay, the display will countdown the
number of seconds remaining before the operator starts.
Reverse Delay
If the gate travel direction is reversed from a user activation or
reversing device, and a reverse delay is set, the display will count
down the delay time in seconds before the operator restarts.
Run Timer
While the gate is opening or closing, the number of seconds
running time is displayed.
