Controlled Products Systems Group LA400 - Manual (Page 6)

6
1/4" (6 mm) or larger
depending on Loop
Wire size
STREET
COMPLEX
OR
PARKING LOT
Telephone
Entry System
Inte
rrupt
Loop
Shad
ow
Loo
p
Interr
upt
Loop
Photo Eye for
Open Cycle
Photo Eye for
Close Cycle
Run Twisted Wire*
from Loop to Operator
Seal Loops*
Loop Wire Layer*
4' (1.2 m)
Ty
pical
4'
(1.2 m)
Typical
1-1/2"
(37 mm)
Shadow loop should be positioned in direction
of gate travel. Pull-to-open illustrated.
The shadow loop input is only active when the
gate is in the fully open or fully closed positions.
STREET
Interrupt
Loop
COMPLEX
OR
PARKING LOT
Telephone
Entry System
Gate 2
Photo Eye for
Open Cycle
Shadow
Loop
Interrupt
Loop
Photo Eye for
Close Cycle
Gate 1
Control
Box
Junction
Box
Extension Cable
1/4" (6 mm) or larger
depending on Loop
Wire size
Seal Loops*
Loop Wire Layer*
Run Twisted Wire*
from Loop to Operator
4'
(1.2 m
)
Typical
4' (1.2 m
)
Ty
pica
l
1-1/2"
(37 mm)
Shadow loop should be positioned in direction
of gate travel. Pull-to-open illustrated.
The shadow loop input is only active when the
gate is in the fully open or fully closed positions.
SWING GATE SYSTEM
DUAL SWING GATE SYSTEM
S U G G E S T E D E N T R A P M E N T P R O T E C T I O N D E V I C E L O C A T I O N S
