Page 12
November, 2003
402 Operator And
455 D Control Panel Installation Manual
402 P
ARTS
L
IST
POS PART NO. DESCRIPTION QTY
1 2036 Galvanized Nut (8mm) 1
2 7220015 Rear Bracket 1
3 7284005 Rear Bracket Plate 1
4 7182075 Short Pin 1
5 7221115 Rear Fork 1
6 2037 Self-Locking Nut (8mm) 1
7* 7109145 Strain Relief 1
8* 7109155 Strain Relief Nut 1
9* 7039305 Strain Relief Brass Washer 1
10* 2581 Fiber Washer 1
11 7514055 Electric Power Cord 1
12 7170435 Rear Flange 1
13 7099101 Gasket (D80) 2
14 7450005 Operator Body 1
15 N/A Self-Threading Screw 1
16 7119475 Silent Block 2
17 2365 Motor Bolt (4mmX50) 4
18 2366 Lock Washer 4
19 2367 Hex Nut (4mm) 4
20** 77000425 115V 1400 RPM Motor 1
21 7119485 Vibration Dampener 2
22 N/A Vent Screw Label 1
23 7182175 Long Pin 1
24 N/A Socket Head Screw
(5X20mm) 8
25 7110015 Plug (Oil) 1
26 2274 Vent Screw (4x6mm) 1
27 7094065 Gasket (Copper) 1
28 3204395 1 Lt Lobe Pump 1
29 N/A Pump Pin 2
30 7203275 By-Pass Protection Cover 1
31 760285 Spacers (Protective Cover) 2
32 7271545 Protective Cover End Cap 1
33 7114025 Protective Cover Plug 1
34 7272085 Protective Cover 1
35 4304015 Front Mounting Bracket 1
36 7182355 Pin Front Bracket 1
37 N/A Black Plastic Screw 1
38 7090010015 O-Ring (3) 3
39 N/A Stainless Steel Screw
(2.9mm x 6.5mm) 2
POS PART NO. DESCRIPTION QTY
101 4404065 Inlet Valve 2
102 N/A O-Ring 5
103 7049135 Valve Retainer 2
104 4180205 Blank Lock Valve 1
105*** 4180135 Green By-Pass Valve 1
106*** 4181045 Red By-Pass Valve 1
107 7090150 O-Ring (By-Pass Valve) 2
108 7210025 By-Pass Spring 2
109 7119335 By-Pass Seat 2
110 7090350 O-Ring (Front Flange) 2
111 7090665 O-Ring (Alum Retract Tube) 2
112 7361315 Retract Tube (Alum) 1
113 7230225 Tie-Rod (Cylinder) 4
114 N/A O-Ring (Front Flange Internal) 1
115 N/A Star Washer 4
116 4994165 Front Flange 1
117 4350065 Piston Assembly 1
118 7095035 Piston Rod Packing 1
119 7366065 Cylinder 1
120 7271555 Protective Cover Guide 1
121 7090300 O-Ring (Shuttle Piston) 1
122 4180285 Shuttle Piston 1
123 4404085 Lock Valve 1
124 4180355 Manual Release 1
125 713002 Triangular Release Key 1
126 N/A Galvanized Screw 1
127 709069 O-Ring (Manual Release) 1
128 4994365 Valve Body (CBC) 1
129 7049005 Brass Retainer 1
130 3905235 Skin Pack 1
131 2168* Seal Kit 1
132 6105 1 Qt. Monolec Oil 1
∗ Included in Kit #2167A*
∗ * 220V 1400RPM Motor Part #77000415
∗ ** Items include item #107, 108, and 109 in a kit
