Page 4
February, 20 09
400 O pe rator And
455 D Control Panel I nst allatio n M anual
T
ECHNICAL
D
ATA
1 The operator requires external locks.
2 Locks in the extended position. The hydraulic lock is a service device, not a security device.
3 Locks in the retracted position. The hydraulic lock is a service device, not a security device.
4 Locks in both the extended and retracted positions. The hydraulic lock is a service device, not a security device.
5 External locks are recommended if the gate leaves are 12 ft (3.6 m) or longer.
6 The time may vary ±10%.
7 Your standard 220 VAC power source meets the specification for 230 VAC, +6 or -10%.
400 Model
Parameter Standard High Speed Slow Speed Long (EG)
Model
CBC 2
CBA 3
CBAC 4
SB 1
CBCR 2
CBAR 3
CBACR 4
SBS 1 CBC 2 SBS 1
CBAC 4
Duty type Apartment, subdivision, industrial, and commercial applications
Duty cycle 80 Cycles/ Hour
Maximum leaf length 5 , ft (m) 16 (5.4) 12 (3.6) 20 (6) 18 (5.4) 22 (6)
Maximum leaf weight, lb (kg) 1300 (600) 900 (400) 2000 (900) 1500 (600) 2200 (600)
Maximum leaf swing, deg 115 125
Thrust and traction, lb (kg) 0–1760 (0–800)
90 deg opening time, sec 6 17 12 23 18 27
Operating temperature range, deg F (deg C) -33 to 165 (-36 to 75)
Thermal cut out, deg F (deg C) 212 (100)
Hydraulic locking Opened and/or closed None Opened and/or closed
Operator dimensions,
l ´ w ´ h, in. (cm) 40 X 3 5/16 X 3 5/16
(102 X 8.5 X 8.5)
47 1/2 X 3 5/16 X 3 5/16
(121 X 3 X 8.5)
Operator weight, lb (kg) 19 (8.6) 23 (10.4)
Power voltage required, VAC 7 115 VAC ±10%, 60 Hz, or 230 VAC +6 or -10%, 60 Hz
Amp Draw 115V = 1.5 Amps; 230V = 1 Amp
Type of oil Lubrication Engineers - MONOLEC 6115
Oil quantity, qt (l) 2 1/3 (2.2) 2 7/8 (2.7)
