Page 15 American Access Systems / Security Brands, Inc.
Problem Solution
When I enter 1 2 5 1 on the keypad the gate will
not open.
1 2 5 1 is the Master Code or programming access code.
It will not open the gate unless the unit is in sleep mode.
Program a gate access code into the unit using Sub-Mode 1
(listed in the programming instructions).
No response from keypad.
Adjust the MIC and /or SPEAKER pots on circuit board to
desired levels. A m Verify power input across the two white
wires on the main harness. Check blue night light LED’s to
see if they are on. Check for burn marks on the circuit board
from a lighting surge. Contact American Access Systems,
Inc. aximum of 5 turns clockwise is allowed.
After I enter the latch code to hold the gate open
it closes or cycles open and shut. When I enter a
valid Access Code the gate does not open.
An open override circuit must be enabled in the gate
operator to prevent the timer circuit from overriding the
keypad when it is in a latch mode. Contact Gate Operator
manufacturer.
When I enter a valid Access Code the gate does
not open.
Locate the two wires attached to the Brown and Orange
wires on the main wire harness, then, touch them together.
If the gate does not open, check wiring or the connection
terminals on gate operator. If the gate opens, contact
American Access Systems.
I connected the two white power wires together to
one power source wire and the other power source
wire to the green wire but the keypad doesn’t work.
The green wire is for EARTH GROUND only. Connect one
white wire to one power source wire and the other white
wire to the second power source wire.
When I press 1 2 5 1 on the keypad nothing hap-
pens and I hear an endless set of error tones.
Contact American Access Systems Inc.
I want to reset my keypad but when I push the reset
button nothing happens.
Consult instructions regarding MASTER and UNIT reset for
proper reset sequence.
Troubleshooting
