PROGRAMMING OPTIONS
Select Door Sense or Inhibit Input
Default: Door Sense
The input on terminal block J4, terminal #3 can be programmed
for DOOR SENSE or INHIBIT.
Press: 1 0 # Input #
Input = 1 for Inhibit,
= 0 for Door Sense
When programmed for DOOR SENSE, if an open condition on
the input occurs before access is granted (with an entry code or
with the request-to-enter input) a FORCED ENTRY output will
occur. If an open condition remains 60 seconds after a relay
activation for access, a DOOR AJAR output will occur.
When programmed for INHIBIT, a closed condition on the input
will prevent relay #1 from activating when access is requested
(with an entry code). This mode is typically used with an external
timer to disable the access device at certain times.
Select Forced Entry Output Default: Output #3
Sets which output activates if the Door Sense input opens before
access is granted. This output is not timed.
Press: 1 1 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Select Door Ajar Output Default: Output #4
Sets which output activates if the Door Sense input stays open after
access is granted. This output is not timed.
Press: 1 2 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Select Keypad Lockout Output Default: No Output
Sets which output activates when the keypad is “locked out” after too
many incorrect entry code attempts. The lockout time is 60 seconds.
Press: 1 3 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Select Keypad Active Output Default: No Output
Sets which output activates when any keys are pressed. This output
is timed.
Press: 1 4 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Select Alarm Shunt Output Default: No Output
Sets which output activates during the time access is granted. (Use
this output to shunt alarm contacts attached to the access door.) This
output may be timed or latched.
Press: 1 5 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3,
4 = Output #4 0 = No Output
Select Request-to-Enter Output Default: Relay #1
Sets which output activates when the Request-to-Enter input is
grounded. This output remains activated for at least the length of time
specified by the On-times for the relays or outputs. If the
Request-to-Enter input continues to be grounded beyond the time
specified by the On-times for the relays or outputs, the output will
remain activated as long as the Request-to-Enter input remains
grounded.
Press: 1 6 # Output #
Output = Output to Activate (0-4)
1 = Relay #1 2 = Relay #2 3 = Output #3
4 = Output #4 0 = No Output
Relay #1 On-time Default: 2 Seconds
Sets the length of time Relay #1 activates when triggered.
Press: 2 1 # Seconds #
Seconds = Output time in seconds (0-60)
Relay #2 On-time Default: 2 Seconds
Sets the length of time Relay #2 activates when triggered.
Press: 2 2 # Seconds #
Seconds = Output time in seconds (0-60)
Solid-state Output #3 On-time Default: 2 Seconds
Sets the length of time Output #3 activates when triggered.
Press: 2 3 # Seconds #
Seconds = Output time in seconds (0-60) 99 = Toggle mode
Solid-state Output #4 On-time Default: 2 Seconds
Sets the length of time Output #4 activates when triggered.
Press: 2 4 # Seconds #
Seconds = Output time in seconds (0-60)
99 = Toggle mode
Set Downlight On-Time Default: 2 Minutes
Sets the time duration that the downlight remains on after a key press.
Press: 2 5
#
Duration
#
0 = Always off 1 = 1 minute 2 = 2 minutes 3 = 3 minutes
4 = 4 minutes 99 = Always on
