COMPONENT LOCATIONS
WIRING DIAGRAM
TACTILE
KEYPAD
YELLOW
"LOCKOUT"
INDICATOR RED/GREEN
POWER/ACCESS
INDICATOR
NIGHT
LIGHT
TERMINAL BLOCK J4
POWER AND INPUTS
KEYLOCK
TERMINAL
BLOCK J3
OUTPUTS
JUMPER JP1
REMOVE TO
REDUCE
BEEPER SOUND
JUMPER JP2
RESETS
MASTER CODE
Figure 1. Component Locations
J4
1
2
3
4
5
6
J3
1
2
3
4
5
6
7
8
9
POWER
INHIBIT
COMMON
REQUEST-TO-ENTER
EARTH GROUND
N.O.
COMMON
N.C.
OUTPUT #3
OUTPUT #4
N.O.
COMMON
N.C.
COMMON
GROUND
AK-11
GATE OPERATOR
INHIBIT
TIMER
AUXILIARY
POWER
OPEN
J4
1
2
3
4
5
6
J3
1
2
3
4
5
6
7
8
9
DOOR SENSE
COMMON
REQUEST-TO-ENTER
EARTH GROUND
N.O.
COMMON
N.C.
OUTPUT #3
OUTPUT #4
N.O.
COMMON
N.C.
COMMON
GROUND
AK-11
FIRE
ACCESS
ELECTRIC
DOOR
STRIKE
OPEN
DOOR SWITCH
ALARM CONTACT
OPTIONAL WIRING
REQUIRED WIRING
POWER
SUPPLY
RELAY #1
TO ALARM
SYSTEM
TO ALARM
SYSTEM
POWER
RELAY #2
RELAY #1
RELAY #2
TYPICAL DOOR INSTALLATION WIRING TYPICAL GATE INSTALLATION WIRING
Figure 2. Wiring Diagram
