TurboVUi Pocket™
for Android™ and iPhone™/iPad™ Quick-Start Guide
3
When connecting using an external (WAN) Wi-Fi or 3G/4G Cellular Network:
Since the connection must pass through a firewall with a port forwarding rule, the
Server IP parameter must be entered using the
following format:
aaa.bbb.ccc.ddd:ppppp
where aaa, bbb, ccc, and ddd are the four octets of the firewall IP address, and ppppp is the port number. The following
example would be used to connect to the demo TurboVUi IP Gateway at CTI:
198.144.49.99:48222
Since 48222 is the default port number used by TurboVUi clients, the port number is not necessary in the example above.
3. To switch connections between several TurboVUi IP Gateways, touch the Gateway History button (folder icon) located in the
upper right corner of the TurboVUi Settings (Android) or App Settings (iOS) screen, and then select a previously used IP Address.
4. A volume slider for receive audio is also located on this Settings screen.
5. To display the Radio screen from the Settings screen, touch the Back button on the Android device, or the Radio menu button on
an iPhone or iPad.
M AKING A V OICE C ALL
Make a call to a radio subscriber by using the following steps:
1. Touch the Subscriber List button to show a list of subscriber radios and Groups. Touch a subscriber or group to select it. An icon
next to each will have the following meaning:
a. “Default” indicates the default group programmed into the
XPR4550 Control Station Radio.
b. A green dot indicates a radio subscriber that is available as
determined by the radio system’s ARS reporting method.
c. A red dot indicates a radio subscriber that is not available,
as determined by the radio system’s ARS reporting method.
The radio subscriber may be out of the radio coverage area,
or have the radio turned off.
d. A blue triangle indicates a group of subscribers as
programmed in the TurboVUi IP Gateway.
2. Touch and hold the PTT button to make a call. When the radio channel is keyed-up, the PTT button will be shaded red.
3. While holding the PTT button, speak with your mouth within eight inches of the mobile device microphone.
4. Release the PTT button when you are finished.
S ENDING A T EXT M ESSAGE
Send a text message by using the following steps:
1. For an Android device, touch the Menu button (usually indicated by three horizontal lines) and then touch Messaging . For an
iPhone/iPad, touch the Text Message icon located at the bottom of the screen. The “Messaging” screen will be displayed.
2. Touch a subscriber or group to select it. An icon next to each will have the following meaning:
a. “Default” indicates the default group programmed into the XPR4550 Control Station Radio.
b. A green dot indicates a radio subscriber that is available as determined by the radio system’s ARS reporting method.
c. A red dot indicates a radio subscriber that is not available as determined by the radio system’s ARS reporting method.
The radio subscriber may be out of the radio coverage area, or have the radio turned off.
d. A blue triangle indicates a group of subscribers as programmed in the MOTOTRBO™ radio system.
3. Enter the text message using the on-screen keyboard, and then touch the Send button.
4. To return to the Radio display screen, touch the Back

button on the Android device, or touch the Radio icon located at the
bottom of the screen of an iPhone/iPad.
Subscriber Selected &
Subscriber List Button
Radio Display
Radio Menu Buttons
Channel Up/Down Buttons
PTT Button
