TurboVUi Pocket™

for Android™ and iPhone™/iPad™

Quick-Start Guide

2

Device Compatibility

Android Phone and Tablet

The Android device must have an Operating System that is at least Version 1.5. In addition, the Android device must support default
audio format of 11025 samples a second, 16 bit samples, monophonic.

iPhone and iPad

An iPhone or iPad must have an Operating System that is at least Version 4.0.

TurboVUi IP Gateway

The TurboVUi Pocket mobile app requires

TurboVUi IP Gateway

Version 5.0.10 or higher

.

Port Forwarding

If the 3G/4G cellular network or an external Wi-Fi network will be used to connect an Android or iPhone/iPad mobile device to a
TurboVUi IP Gateway, then a port forwarding rule must be configured within the firewall connecting the TurboVUi IP Gateway
modules to the ISP (Internet Service Provider). The TurboVUi IP Gateway accepts incoming messages on TCP Port # 48222.

The default port for the TurboVUi Pocket mobile app is also TPC part # 48222, but another port number may be specified. See Step 2
of “Connect to a TurboVUi IP Gateway" below.

If multiple TurboVUi IP Gateways are installed, a port forwarding rule must be configured for each TurboVUi IP Gateway, using
distinct TCP ports.

See

www.portforwarding.com

for detailed instructions for the specific firewall or router in use at your site.

Licensing

User Connections installed on the License File in a TurboVUi IP Gateway can be used for connections to an Android or iPhone/iPad
mobile device running the TurboVUi Pocket mobile app, as well as PCs or laptops running the TurboVUi Solo client. One User
Connection is needed for each simultaneous device connected to the IP Gateway for as long as the application is running.

D

OWNLOAD THE

T

URBO

VU

I

P

OCKET

A

PP

Download the free TurboVUi Pocket app from the Android Market (or Play Store) or the Apple™ App Store, depending on which
device is being used. Search for “turbovui” to locate the application.

For iOS devices, be certain to search for “iPhone Apps” (not

“iPad Apps”).

Follow the prompts to install the application on the mobile device.

C

ONNECT TO A

T

URBO

VU

I

IP

G

ATEWAY

When the TurboVUi Pocket mobile app is first run, it may be configured with the IP address of CTI’s demo TurboVUi IP Gateway
located in Cincinnati Ohio.

To connect to a specific TurboVUi IP Gateway, change the target IP address using the following steps.

1.

For an Android device, touch the

Menu

button (usually indicated by three horizontal lines), and then

touch

TurboVUi Settings

. For an iPhone or iPad, touch the

App Settings

icon at the bottom of the screen.

A screen similar to the one at right will be displayed.

2.

Enter the IP Address of the TurboVUi IP Gateway, along with the appropriate Username and Password,
and then touch the

Connect

button. For CTI’s demo IP Gateway in Cincinnati, use the following:

Server IP: 198.144.49.99

Username: demo

Password: demo

To connect to another TurboVUi IP Gateway, use the IP address, Username, and Password obtained
from your IT administrator. If certain parameters are blocked by the on-screen keyboard, scroll the
page up or down by dragging your finger on the screen.

When connecting using Wi-Fi:
To adjust the Wi-Fi settings for an Android device, touch the

WiFi Settings

button to display the Wi-Fi

setup screen. To adjust the Wi-Fi settings for an iPhone or iPad, press the

Home

button on the

device and then use the

Settings

icon
