5.2 Configuring a 1:3 Audio/Video DA for Component (YUV) or RGB
Configure a 1:3 Audio/Video DA for component (YUV) or RGB by
combining 3 CVG-3AVR/B units, as Figure 4 illustrates.
Connect 1 the 1:3 Audio/Video DA for component (YUV) or RGB, as follows:
1. Connect the RGB source, by connecting:
The R cable to the first unit’s INPUT connector
The G cable to the second unit’s INPUT connector
The B cable to the third unit’s INPUT connector
2. Connect the first RGB acceptor, by connecting the OUT 1 connector from
the:
First unit to the R cable
Second unit to the G cable
Third unit to the B cable
3. Connect the second RGB acceptor, by connecting the OUT 2 connector 2
from the:
First unit to the R cable
Second unit to the G cable
Third unit to the B cable
4. Connect the third RGB acceptor, by connecting the OUT 3 connector
from the:
First unit to the R cable
Second unit to the G cable
Third unit to the B cable
5. Connect the audio source and acceptors, as required.
6. On each
CVG-3AVR/B unit, connect the 12V DC power adapter to the
power socket and connect the adapter to the mains electricity.
7. Adjust the audio level and the video EQ. and video level, as required, on
the front panel on the first CVG-3AVR/B unit.
This adjusts the levels on the combined 3 CVG-3AVR/B units.
1 Switch OFF the power on each device before connecting it to your CVG-3AVR/B units. After connecting your
CVG-3AVR/B units, switch on the power on each of the CVG-3AVR/B units and then switch on the power on each device
2 Not illustrated in Figure 4
