8
6 Technical Specifications
Table 3 includes the technical specifications.
Table 3: Technical Specifications
1
of the CVG-3AVR and CVG-3AVB
Inputs: 1 composite video 1 Vpp/75 : RCA connector (CVG-3AVR); BNC connector (CVG-3AVB)
1 stereo audio, 4.8 Vpp / 73k on RCA connectors
Outputs: 3 composite video 1 Vpp/75 : RCA connectors (CVG-3AVR); BNC connectors (CVG-3AVB)
3 stereo audio, 1 Vpp / 150 on RCA connectors
Coupling: AC
Bandwidth: Video: 430MHz (-3dB), 370MHz (-0.1dB), Full Load;
Audio: >100kHz (-3dB), 20kHz (-0.1dB)
Gain Range: Video: -1.1dB to +1.8dB;
Audio: -66dB to +16dB
Maximum Output: Video: 2.0Vpp;
Audio: 5.4Vpp
Video Equalization: 0 to +14.6dB
S/N Ratio:
Video: 73.1dB;
Audio: 83dB
Video Non-linearity: 0.1%
Differential:
Gain: 0.04%; Phase: 0.07 Deg
THD (Audio)/Noise: 0.38% @ 1kHz
2
nd Harmonic: 0.02% @ 1kHz
K-Factor: <0.05%
Dimensions: 16.5cm x 12cm x 4.5cm (6.5” x 4.7” x 1.7”, W, D, H)
Power Source: 12 VDC, 45mA
Weight: 0.6kg (1.3lbs.) approx.
Accessories: 12 VDC power supply
1 Specifications are subject to change without notice
