1
1 Introduction
Congratulations on purchasing your CVG-3AVR and/or CVG-3AVB 1:3
Audio/Video DA, which are ideal for the following applications:
Video/Audio duplication studios
Retail outlets and home theater systems
The package includes the following items:
CVG-3AVR and/or CVG-3AVB 1:3 Audio/Video DA
Power adapter(s)
This user manual
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
3 Overview
The CVG-3AVR and/or CVG-3AVB 1:3 Audio/Video DA are exceptionally
high performance 1:3 distribution amplifiers for video and stereo audio
signals. The CVG-3AVR and/or CVG-3AVB accept one input 1 and
distribute the signal to 3 identical outputs.
Video signals transmit via:
RCA connectors on the CVG-3AVR
BNC connectors on the CVG-3AVB
Both the CVG-3AVR and/or CVG-3AVB include:
RCA connectors for stereo audio signals
Extra wide video bandwidth of 430MHz that allows for high-resolution
data/video signals, SDI (serial digital) video and other specialized signals
An audio level control knob
Front panel cable EQ (equalization) and video level trimmer controls
1 Typically, a composite video source (such as VCR or camera)
