6 Technical Specifications
This section defines the technical specifications
1
for the:
CDA-V31 1:3 Audio-Stereo / Video DA (see Table 4)
CDA-V50 1:5 High Resolution Video DA (see Table 5)
Table 4: Technical Specifications of the CDA-V31 1:3 Audio-Stereo / Video DA
INPUT:
1 composite video, 1Vpp/75 on an RCA connector
1 audio stereo, 1Vpp/33 k on 3.5-mm mini phone connector
OUTPUTS:
3 composite video, 1Vpp/75 on RCA connectors
3 audio stereo, 1Vpp/50 on 3.5mm mini phone connectors
MAX. OUTPUT LEVEL:
VIDEO: 2Vpp
AUDIO: 5Vpp
VIDEO BANDWIDTH (-3dB):
415MHz
AUDIO BANDWIDTH (-3dB):
>100kHz
DIFF. GAIN:
0.05%
DIFF. PHASE:
0.03 Deg
K-FACTOR:
<0.05%
VIDEO S/N RATIO:
73dB
AUDIO S/N RATIO:
84dB Unweighted
CROSSTALK:
-70dB @20kHz
CONTROLS:
Video level: -2.6dB to 5.9dB; audio level: 0dB to 5.9dB
COUPLING:
VIDEO: AC
AUDIO: AC
AUDIO THD+NOISE:
0.01%
AUDIO 2nd HARMONIC:
0.003%
POWER SOURCE:
12 VDC, 50mA
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76” x 2.83” x 0.95”, W, D, H.)
WEIGHT:
0.28kg. (0.62 lbs.) approx.
ACCESSORIES:
Power supply, mounting bracket
Table 5: Technical Specifications of the CDA-V50 1:5 High Resolution Video DA
INPUT:
1 video, 1Vpp/75 on a BNC connector
OUTPUTS:
5 video, 1Vpp/75 on BNC connectors
MAX. VIDEO OUTPUT:
1.5Vpp
VIDEO BANDWIDTH (-3dB): 400MHz
DIFF. GAIN:
0.05%
DIFF. PHASE:
0.09 Deg
K-FACTOR:
<0.05%
S/N RATIO:
72dB
CONTROL:
Level: -2dB to +5.6dB
COUPLING:
AC
POWER SOURCE:
12 VDC, 35mA
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76” x 2.83” x 0.95”, W, D, H.)
WEIGHT:
0.3kg. (0.6 lbs.) approx.
ACCESSORIES:
Power supply, mounting bracket
1 Specifications are subject to change without notice
