XNET Network Weatherproof Camera Installation Manual
21 / 23
4 4 . . 2 2 . . W W e e b b V V i i e e w w e e r r P P a a g g e e
Web viewer page contains a Video monitor screen and menu option buttons.
Figure 4-2. Web Viewer Page
Item Sub Item Description
Capture -
Captures and saves the current image as a still picture.
The image is saved as jpeg file in the following folder:
C:₩xNetCapture
Setting -
Brings up Menu screen in which all XNET features can be configured.
Please refer to [XNET Owner’s Manual] for detail.
PTZ -
Opens up PTZ page.
This page can set up digital PTZ of the network camera and control of
PTZ movement.
Please refer to [XNET Owner’s Manual] for detail.
Live View
Main Stream Displays the Main Stream Video Image.
Sub Stream
Displays the Sub Stream Video Image.
Enable Dual-Codec in Video Setup Page to view the Sub Stream Video.
Please refer to [XNET Owner’s Manual] for detail.
