CNB IDC4050F User Manual
Page 42
XNET User Manual
42 / 46
ITEM
DESCRIPTION
Sensor Setting
Signal Type
Selects the signal type for Alarm Input Port between Normally Close
and Normally Open.
Alarm Setting
Out Interval
Configures interval between repeating Alarm Out signals between
1 and 120 seconds.
Force
Alarm Control
Alarm
Control
Select the Alarm Control type either Auto or Manual.
Auto : Rings the alarm automatically during the out interval depending
on the Alarm Input Signal Type.
Manual : User can ring or stop the alarm manually using Index page’s
Alarm button.
Save
-
Applies and saves changes.
Reset
-
Recalls previously saved configurations.
