5. Specification
IDC4050F/IDC4050IR/IDCP4050VF/IDC4050VR
Specifications
Camera
Signal System
Progressive image processing
Scanning System
16:9 Progressive
Pixel Clock
80MHz
Image Sensor
1/3" Progressive CMOS Sensor
Sync. System
Internal
Effective Pixels Number
1920 (H) x 1080(V) 2.0 Mega
Horizontal Resolution
1100 TV Lines
Video Output Level
Select NTSC/PAL 1.0Vp-p (BNC 75Ω, composite)
Lens
Built-in Fixed Mega pixel Lens, f=4.0mm, F 1.8 *IDC4050F / IDC4050IR
Built-in DC Iris Vari-focal Lens, f=3 ~ 10mm, F 1.3 *IDC4050VF / IDC4050VR
Min. Illumination
1Lux (Color, DSS On), 0.05Lux (B/W, DSS On) *IDC4050F
1Lux (Color, DSS On), 0.00Lux (IR LED On) *IDC4050IR
0.8Lux (Color, DSS On), 0.1Lux(B/W), 0.05Lux (B/W, DSS On) *IDC4050VF
0.8Lux (Color, DSS On), 0.1Lux(B/W), 0.00 Lux (IR LED On) *IDC4050VR
IR LED and Sensor
850nm / 45˚ IR LED 18EA, Sensor 1EA
*IDC4050IR / IDC4050VR (IR model Only)
IR LED Lighting Distance
Max. 15m
Day & Night System
ICR(CDS Type)
Back Light Compensation
On/Off
Flickerless
On/Off
White Balance
Auto/Manual
Exposure
Auto/Manual
Functions
B/W
Electronic Shutter Speed
NTSC : 1/7.5 ~ 1/8000 (21 Step)
PAL : 1/7.5 ~ 1/8000 (21 Step)
Video / Audio
Compression
H.264 / MJPEG
Frame rate
Single Mode : Main(H.264@30fps) *1080p Mode : Main(H.264@30fps)
Second(H.264@30fps/MJPEG) *Main(720p)/Second(D1)
Resolution
Full HD(1920 x 1080), SXGA(1280 x 1024, 1280 x 960) 720P(1280x720),
D1(720 x 480 / 720 x 576), VGA(640x480), CIF(352 x 240 / 352 x 288)
Audio
Two-way (Full duplex / G.711)
Network
Protocol
IPv4, HTTP, HTTPs, UDP, TCP, RTSP, RTP, SMTP, FTP, ICMP, DHCP, UPnP, Bonjour,
ARP, DNS, DynDNS, NTP, IGMP(Multicast) , QoS, SNMP *) OnVif
Supported DDNS
1. DDNS 2. DynDNS.org
3. Reference code with SDK
LAN Interface
Ethernet 10/100 Base-T (RJ-45 Type)
Support PoE
Standard IEEE 802.3af supported
Security
Access level setup
Multiple user access levels with password protection
Network Security
IP Filtering
Alarm and Event
Management
Image detection
Motion detection (Select 3 Regions - each area)
Sensor detection
Sensor In, Scheduling, Alarm out
After Event process
JPEG Image upload over FTP server / SMTP (E-mail server)
Applications
Browser
Internet Explorer 6.0 or later
Monitoring Application
NVR, CMS and Utility (IP-Installer, etc)
Maintenance
System Upgrade
Firmware upgrade over HTTP
Mechanical
Operating Temperature
0℃ ~ 40℃
Power
DC 12V Max. 7 W
Dimensions / Weight (Net)
92(Ø ) mm
