9. OSD MANUAL
- CAM TITLE : Enable user to choose any word in screen(Maximum 10 letter is available)
① A letter Choice from the screen using menu key
② Enable user to move to next menu using LEFT, RIGHT KEY in LOCATION.
③ By using UP, DOWN, LEFT, RIGHT KEY, enable user to choose any letters in
LOCATION and then get back to previous step.
④
Enable user to finish words choice and position by using LEFT, RIGHT KEY in RETURN
- LANGUAGE : Enable user to set up an OSD language
-> ENGLISH, CHINESE, RUSSIAN, SPANISH, GERMAN, FRENCH, PORTUGUESE, JAPANESE.
- COMM ADJUST :
Enable user to set up CAMERA ID, BAUDRATE.
① CAM ID : Enable user to set up Camera ID (0~255).
② BAUDRATE : A communication speed to Communicate
with external device. (2400, 4800, 9600, 19200).
- PRIVACY : Privacy is the function that covers the
some part on screen to prevent private life
(Maximum 4 point covered).
① ZONE : Enable user to set up a position from 0 to 3 area.
② MASK : Enable user to set up screen output of chosen position.
③ V START : Mask Vertical start position.
④ V END : Mask Vertical end position.
⑤ H START : Mask Horizontal start position.
⑥ H END : Mask Horizontal end position.
⑦ COLOR : Set the mask color.
⑧ TRANSPARENCY : Set the transparency of the mask.
⑨ MOSAIC : Mosaic is set to mask the effect.
⑩ INITIAL : Enable user to initialize setting of
PRIVACY MENU
22
CAM TITLE
0123456789ABCDEFGHIJK
LMNOPQRSTUVWXYZ!-()<>
SPA>>
<
TITLE SET
LOCATION [┛]
RETURN
[TITLE LOCATION]
TITLE SET
[U] [D] [L] [R] [M] <
COMM ADJUST
>CAM ID 1
BAUDRATE 9600
RETURN
PRIVACY
>ZONE NO 0
MASK MODE ON
V START 7
V END 12
H START 10
H END 19
COLOR 1
TRANSPARENCY 0%
MOSAIC OFF
INITIAL
RETURN
