6. INSTALLATION
• MONITOR CONNECTION
11
When you install the camera, please glue up the end of cable to
keep it stable in order to protect the camera from the humidity problems.
DC12V/AC24V
DC12V/AC24V
BNC FEMALE
DC 12V POWER SUPPLY or
AC 24V POWER SUPPLY
DC 12V POWER SUPPLY or
AC 24V POWER SUPPLY
VIDEO IN
VIDEO IN
RS485
MONITOR
MONITOR
