MAIN
MENU
1st Sub
MENU
2st Sub
MENU
3st Sub
MENU
4st Sub
MENU
SHUTTER
/ AGC
AUTO
HIGH LUMINANCE
MODE AUTO IRIS, SHUT+AUTO IRIS
BRIGHTNESS (000 ~ 255)
LOW LUMINANCE
MODE AGC,OFF
BRIGHTNESS x0.25,x0.50,x0.75,x1.00
RETURN
MANUAL
MODE SHUT+AGC
SHUTTER
1/50(PAL),1/120(PAL)
1/60(NTSC),1/100(NTSC)
1/250,1/500,1/1000,1/2000
1/4000,1/10000
AGC 6,12,18,24,30,36,42,44.8
RETURN
WHITE
BAL
ATW
SPEED (000 ~ 255)
DELAY CNT (000 ~ 255)
ATW FRAME x0.50,x1.00,x1.50,x2.00
ENVIRONMENT INDOOR,OUTDOOR
RETURN
PUSH
USER1
B-GAIN (000 ~ 255)
R-GAIN (000 ~ 255)
RETURN
USER2
B-GAIN (000 ~ 255)
R-GAIN (000 ~ 255)
RETURN
ANTI CR
MANUAL
LEVEL
NTSC:(30 ~ 115)
PAL:(28 ~ 134)
RETURN
PUSH LOCK
BACK LIGHT OFF,BLC,HLC
PIC
ADJUST
MIRROR OFF,ON
BRIGHTNESS (000 ~ 255)
CONTRAST (000 ~ 255)
SHARPNESS (000 ~ 255)
HUE (000 ~ 255)
GAIN (000 ~ 255)
RETURN
ATR
ON
LUMINANCE LOW,MID,HIGH
CONTRAST LOW,MIDLOW,MID,MIDHIGH,HIGH
RETURN
OFF
*
ATR (Adaptive Tone-Curve Reproduction):
The function provides gradation compensation to improve the contrast of subjects both low luminace areas and
high luminance areas exist in the same picture
13
9 . O S D M E N U S T R U C T U R E
