Signal Format NTSC PAL
Image Device 1/3" 960H SONY EXview HAD CCD II
Scanning System 2 : 1 Interlace
Scanning Frequency 15.734KHz(H), 59.94Hz(V) 15.625KHz(H), 50Hz(V)
Total Pixels 1020(H) X 508(V) 1020(H) X 596(V)
Effective Pixels 976(H) X 494(V) 976(H) X 582(V)
H.Resolution 750TV Lines
S/N Ratio More than 50dB(AGC OFF)
Min.Illumination 0Lux (IR LED On)
Sync System Internal
Gamma r= 0.45
Video Output Level 1.0 Vp-p Composite(75Ω)
OSD Built in (Inner Key / Joystick)
BLC OFF / BLC / HLC
White Balance ATW / PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH-LOCK
2DNR OFF / ON (Level adjustable)
ATR OFF / ON (Level adjustable)
Function MIRROR / BRIGHTNESS / CONTRAST / SHARPNESS / HUE / GAIN
Privacy Masking 4 Zones
Motion Detection 4 Zones
Day & Night AUTO
Lens Aspheric Vari-focal DC IRIS Lens
Language
ENGLISH / JAPANESE / GERMAN / FRENCH / RUSSIAN /
PORTUGUESE / SPANISH / CHINESE
IP Rating IP66 (Weather proof)
IR LED Hi-power LED 5ea(850nm) - Distance: Up to 45m
Operating Temperature 14°F~122°F(-10°C~+50°C)
Storage Temperature -4°F~140°F(-20°C~+60°C)
Humidity Less than 80%
Power
Consumption
DC12V DC12V ±10% Max.350mA
DUAL DC12V ±10% Max.450mA / AC24V ±10% Max.5.6W
Option DUAL (AC24V / DC12V)
Dimension 67(Ø) x 233.8(mm)
Specifications and designs are subject to change for improving
the functionality of this product without notice.
12
8 . S P E C I F I C A T I O N
