7. SPECIFICATION
NTSC PAL
Image Sensor 1/3” 960H SONY Double Scan Super HAD CCD II
Scanning System 2 : 1 Interlace
H Resolution. 750TV Lines
Scanning Frequency 15.734KHz(H), 59.94Hz(V) 15.625KHz(H), 50Hz(V)
Total Pixels No. 1028(H) X 508(V) 1028(H) X 596(V)
Effective Pixels No. 976(H) X 494(V) 976(H) X 582(V)
S/N Ratio More than 50dB(AGC OFF, 3DNR ON)
Min. Illumination Color:0.1Lux, BW:0.1Lux ([email protected], AGC 36dB) 0.000001Lux (DSS x256)
Sync System Internal
Gamma r= 0.45
Video Output 1.0 Vp-p Composite(75Ω)
Lens Board Lens
Digital Zoom Ratio 3x
Electronic Shutter 1/60 ~1/100,000sec 1/50 ~1/100,000sec
Digital Slow Shutter OFF, 2 ~ 256 Field
Flickerless ON / OFF
WDR ON / OFF (Level adjustable)
BLC ON / OFF (Level adjustment, Area selection)
HLC ON / AUTO / OFF (Level adjustable)
AGC OFF, 6 ~ 36dB
DNR(2D/3D) ON / OFF (Level adjustable)
Image Function Image reverse(Normal/Flip), Freeze, Contrast, Sharpness
Day & Night COLOR / BW / AUTO(DIGITAL D/N)
Motion Detection 4 Zones (Level adjustable, Area adjustment)
Privacy Masking 15 Zones (Area adjustment)
White Balance
ATW / PUSH / USER1 / USER2 / ANTI CR /
MANUAL / PUSH-LOCK
OSD Built in (Joystick)
Language
ENGLISH / JAPANESE / GERMAN / FRENCH /
RUSSIAN / PORTUGUESE / SPANISH / CHINESE
Operating Temperature 14°F~122°F(-10°C~+50°C)
Storage Temperature -4°F~140°F(-20°C~+60°C)
Humidity Less than 80%
Weight
PLASTIC DOME Type: Approx. 200g
VANDAL DOME Type: Approx. 500g
Power
Consumption
DC DC12V (±10%), Max. 140mA
DUAL
DC12V (±10%), Max. 190mA
AC24V (±10%), Max. 2.5W
Dimension (mm)
PLASTIC DOME Type: 119mm x 119mm x 42mm
VANDAL DOME Type: 139mm x 134mm x 49mm
Specifications and designs are subject to change for improving the
functionality of this product without notice.
