11
7. Functions
OSD Menu Structure
• MODE
- INSTALLATION
Installation Mode provides a bright
video screen for adjusting the angle and focus.
- LICENSE-PLATE
License-plate Mode provides high contrast
and clear license plate images for license plate capture.
•
S H U T T E R
1/250,1/500 ~ 1/10000
(adjusted to 1/500sec measure),
1/30K,1/50K, 1/70K, 1/90K, 1/100K.
- Adjusted when LICENSE-PLATE MODE is
performed(Initial value: 1/9000).
- Indicated as “----“ when INSTALLATION MODE
is set.
• NEGATIVE
The user can select positive or negative image.
N e g a t i v e O F F N e g a t i v e O N
•
E X I T
Enables user to EXIT the OSD menu by using
SELECT. If Installation Mode is
selected, the user can see the screen as below.
SETUP
▶ MODE
SHUTTER
NEG. IMAGE
EXIT
LICENSE-PLATE
1/9000
OFF
SETUP
▶
MODE
SHUTTER
NEG. IMAGE
EXIT
LICENSE-PLATE
1/9000
OFF
INSTALLATION MODE
FOCUS VALUE: 2 ↑
SETUP
▶
MODE
SHUTTER
NEG. IMAGE
EXIT
LICENSE-PLATE
1/9000
OFF
