Installation diagrams, Monitor connection, Service video connector – KT&C KPC-LP751NU User Manual
Page 10
10
6. Installation Diagrams
• Monitor Connection
DC12V
DUAL(DC12V/AC24V)
• Service Video Connector
When you install the camera, please glue the end of cable to
keep it stable in order to protect the camera from humidity problems.
Handheld Monitor
DC12V
DC 12V Power Supply
VIDEO IN
Monitor
DC12V/AC24V
DC 12V Power Supply or
AC 24V Power Supply
Video In
Monitor
