5. Specifications
Image Device 1/4" Sony Double Scan, Super HAD CCDⅡ
Effective Pixels NTSC: 976(H)*494(V), PAL: 976(H)*582(V)
Resolution 750 TVL
Lens 30X Optical /10X Digital Zoom(Auto Focus)
View Angle Approx. Approx. 69.5° (Wide end) to 2.46° (Tele end)
Min. illumination 0.2 Lux/ F1.65, 0.001 Lux/DSS, 0.1 Lux/ICR
S/N Ratio More than 50dB
WDR On / Off
DNR 3DNR
Privacy Masking Max. 15 zonves
Electrical
Power Supply
AC24V (±10%) Normal, Built-in Power Line Surge
Power Requirement Adaptor AC24VAC, 1A(2.5A with Heater)
Power Consumption
AC24VAC, 850mA / 15W (without Heater)
AC24VAC, 2A / 43W (with Heater)
Alarm Output 1 Normal Relays 12VDC / 500mA Max (Selectable NC/NO)
Alarm Input 4 Normal Dry Contact (Selectable NC/NO)
Control RS-485 baud rate: 2400~38.4Kbps (default: 2400bps)
Access Time 0.75 second maximum preset recall time
ID (Camera Address) Physical 255
Mechanical
Weight
about 1.5Kg
Dimension Ø 154 x 138(H)mm(Bubble Dome Ø 112)
Pan Angle 360° Continuous rotation
Tilt Range 0 ~ 180°
Speed Maximum Preset Speed: 360°/sec
Flip Rotate 180° at bottom of tilt
Auto Scan 8 Auto Scan include vector scan
Preset Position 210 Position with camera status
Tour 8 Tour(Preset, Pattern, Scan)
Pattern 8 Pattern
On Screen Display
Display camera ID, Title, Mode, and Angle on screen
(Multi-Language)
Multi-language OSD
English, Chinese, Russian, Spanish,
German, Italian, French, Netherlandish
Environment
Certification
CE / FCC / IP66
Operating Temperature
-10 ~ +50°C
With heater : -40C ~ +50C
Heater(Bult-in) On / Off: -5 ~ +5°C
Operating Humidity ~80% RH
Storage Temperature -20°C~60°C / ~90%
IP Rating IP66 (Weatherproof)
Specifications and designs are subject to change for improving the functionality of this product without notice.
