3. Program and Operation
3.5.3 AE Setup (Auto Exposure Setup)
Shutter speed is the duration of the electronic shutter. Set the shutter speed to operate
automatically (Auto) or manually (Numeric Value).
Shutter speed is the duration of the electronic shutter. Set the shutter speed to operate
automatically (Auto) or manually (Numeric Value).
The AGC (Automatic Gain Control or AGC Max Gain) adjusts the brightness of the pictures. The
brightness increases as the number gets higher.
SSNR enhances digital noise reduction properly. There are three settings: Low/Middle/High.
When gain level is higher, SSNR will reduce the noise to make clearer image.
When Input luminance level is too dark, Slow Shutter function (DSS) is set automatically higher.
- Enter into {Main Manu}.
- Select {Camera Setup} and move to {AE Setup} using joystick[▶].
- Set AE mode for Full Auto, Manual, Shutter PRI.
- Press [Open] button or use joystick to save settings.
- Press [Close] button or use joystick to return to previous menu (Back).
AE Mode
Full Auto
Manual
SHUT FIX
WDR
Shutter
(1/1~1/100,000)
X
O (1/1000) O (1/1000)
X
AGC Gain
(00~36dB)
X
O (06dB)
X
X
AGC Max
(Off/Low/Mid/High/Super)
O (default: High)
X
O (High)
O
DSS
(0x2~0x128Fld)
O (Off)
X
X
X
Bright
(00~15)
O (06)
X
O (06)
O
3.5.4 Day & Night Setup
The Day & Night function improves the camera’s sensitivity at night or when the brightness level
of the ambient environment. According to the luminance level, Day & Night filter is automatically
switched.
- Enter into {Main Manu}
- Select {Camera Setup} and move to {Day/Night Setup} using joystick [▶].
- Set Day/Night for Auto, Day or Night.
- Set D&N Detector for Auto, Sensor or Video.
- Set switching time that you want.
- Press [Open] button or use joystick to save settings.
- Press [Close] button or use joystick to return to previous menu (Back)
23
AE SETUP
MODE
: FULL AUTO
SHUT
:
AGC GAIN :
AGC MAX : HIGH
DSS
: OFF
BRIGHT
: 06
SAVE : OPEN
BACK : CLOSE
D/N SETUP
DAY/NIGHT : AUTO
D&N DETECT
: AUTO
D/N DTIME : 03
SAVE : OPEN
BACK : CLOSE
