8. SPECIFICATION
Image Device 2.1Mega Pixel. 3/1" Exmor SONY CMOS
Effective Pixels 1984 (H) x 1105 (V) 30fps
Unit Cell Size(um) 2.8 (H) x 2.8 (V)
Video Output Mode
HD-SDI: 720p60, 720p50,1080p30, 1080p25
TV Out: NTSC / PAL Selectable
Minimum Illumination 0 Lux
Video Output HD-SDI / 1.0 Vp-p Composite (75Ω)
IR LED 850nm , 20ea
IR Beam Range Up to 10M ( 32 Feet )
S/N Ratio More than 50dB
Shutter Speed Auto / Manual selectable
Manual Shutter Speed
1/30(25), 1/60(50), 1/120(100), 1/240, 1/500,
1/1K, 1/2K, 1/4K, 1/8K, 1/16K, 1/30K, 1/60K
D-WDR / BLC OFF / BLC / D-WDR
AGC Max. 29 dB
3DNR OFF / LOW / MIDDLE / HIGH
Day & Night True Day & Night with ICR Mechanism
White Balance AUTO / AUTOext / PUSH / MANUAL
Digital Zoom Ratio 1x ~ 20x
Privacy Masking Zone 24, On / Off
Lens Board Lens
OSD Built-in
Power Consumption DC 12V(±10%), Max. 420mA
Weight Approx. 330g
Dimension(mm) Ø93 X 63
Conformity CE, FCC, KC
Temperature / Humidity
(no condensing)
Operation: 14°F~122°F(-10°C~+50°C / 20~80%)
Storage: -4°F~140°F(-20°C~+60°C / 20~90%)
*Specifications and designs are subject to change for improving the
functionality of this product without notice.
