Benefit from the advantages
AMW 22 – display/operation Efficient weighing with the AMW 22 AMW 22p – display/operation Maximum precision with the AMW
22p
Easy to handle
The operating handle is equally suitable
for both left and right handed operators.
The special lowering valve allows for
loads up to 1000 kg to be lowered par-
ticularly sensitively. The standard fast lift
(to 120 kg) ensures that Euro pallets are
lifted off the floor with only three pump
strokes and the maximum lift height is
achieved in 5 pump strokes.
Maximum precision
The weighing cells are positioned at the
four end points of the forks and ensure
extremely precise weight recording up to
a slanting position of 2°.
Thoroughly robust
Maximum stability is achieved through
the well proven fork construction. Elec-
tronics and display are protected against
dust and water (protection class IP 65).
Application-specific configuration
Two different models of the pallet truck
with weighing device are available to
ensure an application-specific, cost-
effective solution for every application.
Performance characteristics of the
AMW 22:
• 2200 kg weighing capacity.
• Fast lift.
• 1 kg display increments across the
entire measuring range up to 2200 kg.
• Maximum 0.1% deviation from measur-
ing range.
• Protected against moisture and dust (IP
65 rating).
• Automatic zero adjustment, also via
keypad.
• Taring over the full weighing range.
• Addition memory and number of
weighing processes.
• Power supply from 4 x AA / 1.5 volt
batteries sufficient for approx. 1700
weighing processes.
• Automatic shutdown if not used for 3
minutes.
Special equipment AMW 22:
• Tandem design.
Performance characteristics of the
AMW 22p:
• After confirming the weight, the LC
display is automatically adjusted to the
lower weight.
• Maximum 0.1% deviation from
measured weight.
• Protected against moisture and dust (IP
65 rating).
• Plug-in battery module with 12 V / 1.2
Ah incl. Charger.
• 60 h operating time.
• Automatic switch-off after 30 minutes
without activity.
• Automatic multi-range display:
Measuring interval Measuring range
0.2 kg
up to 200 kg
0.5 kg up to 500 kg
1.0 kg up to 2200 kg
Special equipment for the AMW 22p:
• Special functions option
Unit counting by entering or establishing
base unit weight
Button for optional weight in kg or lbs
Backlit display
Date and time
Battery discharge indicator
Entry of 5-digit codes
• Calibrated designs grade III (EU regis-
tration no. T2782).
• Additional battery change module.
• Integrated printer.
• Special fork dimensions.
• Wheel brake and parking brake, foot
brake.
• Anti-static steering wheel.
• Sensitive multi-range display:
Measuring interval Measuring range
0.1 kg
up to 200 kg
0.2 kg up to 500 kg
0.5 kg up to 2200 kg
T_AM
W 22/22p_04201
4_en_UK_000
