1) AMW 22p
2) Ø 82x62 mm tandem tyres
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 11/2012
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model AMW 22 AMW 22p
1.3 Drive manual
1.4 Manual, pedestrian, stand-on, seated, order picker operation hand
1.5 Load capacity/rated load Q t 2.2
1.6 Load centre distance c mm 600
1.8 Load distance x mm 890
1.9 Wheelbase y mm 1110
W
eights
2.1 Service weight kg 99 102
2.2 Axle load, w. load, front / rear kg 578 / 1721 1)
2.3 Axle load, w.o. load, front / rear kg 61 / 38
Wheels / chassis
3.1 Tyres C;V
3.2 Tyre size, at front mm Ø 170x50
3.3 Tyre size, at rear mm Ø 82x96 2)
3.5 Wheels, number front/rear (× = driven wheels) 2/2 or 2/4
3.6 Track width, front b
10
mm 109
3.7 Track width, rear b
11
mm 370
Basic dimensions
4.4 Lift h
3
mm 122
4.9 Height of tiller in drive position min. / max. h
14
mm 1234
4.15 Lowered height h
13
mm 86
4.19 Overall length l
1
mm 1546
4.20 Length incl. back of forks l
2
mm 396
4.21 Total width b
1
/b
2
mm 540
4.22 Fork dimensions s/e/l mm 62 / 170 / 1150
4.25 Width over forks b
5
mm 540
4.32 Floor clearance centre wheelbase m
2
mm 24
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 1763
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 1813
4.35 Turning radius W
a
mm 1303
Perform
-
ance da
ta 5.3 Lower speed, w. / w.o. load m/s 0.09 / 0.02
Elec
-
trics
6.4 Battery voltage/nominal capacity K5 V/Ah 4x 1,5 12 / 1.2
