DFG/TFG 316/320
Standard mast types DFG 316/DFG 320/TFG 316/TFG 320
Lift
h
3
Lowered mast height
h
1
Free lift
h
2
Extended mast height
h
4
Mast tilt for-
ward / back
α/ β
(mm) (mm) (mm) (mm) (°)
DFG 316 / TFG
316
DFG 320 / TFG
320
DFG 316 / TFG
316
DFG 320 / TFG
320
DFG 316 / TFG
316
DFG 320 / TFG
320
Duplex ZT 2900 2016 2023 150 150 3490 3512 6/7
3100 2116 2123 150 150 3690 3712 6/7
3300 2216 2223 150 150 3890 3912 6/7
3500 2316 2323 150 150 4090 4112 6/5
3700 2416 2423 150 150 4290 4312 6/5
4000 2516 2523 150 150 4590 4612 6/5
4300 2716 2723 150 150 4890 4912 6/5
4500 2816 2823 150 150 5090 5112 6/5
Duplex ZZ 3100 2071 2078 1481 1436 3690 3742 6/7
3300 2171 2178 1581 1536 3890 3942 6/7
3500 2271 2278 1681 1636 4090 4142 6/5
3700 2371 2378 1781 1736 4290 4342 6/5
4000 2521 2528 1931 1886 4590 4642 6/5
Triplex DZ 4400 2031 2038 1441 1396 4990 5042 6/5
4640 2111 2118 1521 1476 5230 5282 6/5
4700 2131 2138 1541 1496 5290 5342 6/5
4800 2171 2178 1581 1536 5390 5442 6/5
5000 2241 2248 1651 1606 5590 5642 6/5
5500 2421 2428 1831 1786 6090 6142 6/5
6000 2591 2598 2001 1951 6590 6642 6/5
6500 2771 2778 2181 2136 7090 7142 6/5
7000 2941 2948 2351 2306 7590 7642 6/5
7500 3111 3118 2521 2476 8090 8142 6/5
