ETV/ETM 214/216
e
a
2
s
Q
h
1
h
6
h
7
h
8
m
2
l
2
210
l
7
l
1
x
c
l
4
l
b
5
b
3
b
4
b
11
b
1
a
2
Ast
Wa
␣
␤
h
4
h
3
h
2
y
␣ ␤
b
2
Capacity
900
1000
1100
1200
1300
1400
1500
1600
1700
400 500 600 700 800 900 1000
ETM/V 216
ETM/V 214
Load centre distance “c” in mm
Standard mast types ETM 214/ETV 214/ETM 216/ETV 216
Designation Lift
h
3
(mm)
Closed mast height
h
1
(mm)
Free lift
h
2
(mm)
Extended mast
height
h
4
(mm)
Mast tilt forward /
back
a/ß
(°)
Tilt forks forward /
back 1)
a/ß
(°)
Triplex
DZ
4550 2050 1406 5194 1/5 -
5000 2200 1556 5644 1/5 2/5
5300 2300 1656 5944 1/5 2/5
5600 2400 1756 6244 1/3 2/5
5900 2500 1856 6544 1/3 2/5
6200 2600 1956 6844 1/3 2/5
6500 2700 2056 7144 0,5/2 2/5
6800 2800 2156 7444 0,5/2 2/5
7100 2900 2256 7744 0,5/2 2/5
7400 3000 2356 8044 0,5/1 2/5
7700 3100 2456 8344 0,5/1 2/5
8000 3200 2556 8644 0,5/1 2/5
8300 3300 2656 8944 0,5/1 2/5
8420 3340 2696 9064 0,5/1 2/5
8720 3440 2796 9364 0,5/1 2/5
9020 3540 2896 9664 0,5/1 2/5
9410 3670 3026 10054 - 2/5
9920 3840 3196 10564 - 2/5
10250 3950 3306 10894 - 2/5
10520 4040 3396 11164 - 2/5
10700 4100 3456 11344 - 2/5
1) Fork tilt for ETV series only
