1)

For F (low profile telescopic forks) 1000 kg

2)

In connection with performance package to 0.52 m/s

3)

possible in connection with performance package to 0.4 m/s

In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.

Technical data in line with VDI 2198

Issue: 03/2014

Identifica

tion

1.1

Manufacturer (short form)

Jungheinrich

1.2

Model

ETX 513

ETX 515

ETX 513

ETX 515

1.3

Drive

Electrics

1.4

Manual, pedestrian, stand-on, seated, order picker operation

tri-lateral

stacker

tri-lateral

stacker

Bi-lateral

stacker

Bi-lateral

stacker

1.5

Load capacity/rated load

Q t

1.25

1.5

1.2

1)

1.2

1)

1.6

Load centre distance

c mm

600

1.8

Load distance

x mm

168

193

168

193

1.9

Wheelbase

y mm

1764

2094

1764

2094

W

eights

2.1

Service weight

kg

6540

7530

6540

7530

2.2

Axle load, w. load, front / rear

kg

5736 / 2058

6540 / 2490

5736 / 2058

6540 / 2490

2.3

Axle load, w.o. load, front / rear

kg

3810 / 2730

4350 / 3180

3810 / 2730

4350 / 3180

Wheels /

chassis

3.1

Tyres

Vulkollan

3.2

Tyre size, at front

mm

Ø 295 x 144

Ø 380 x 192

Ø 295 x 144

Ø 380 x 192

3.3

Tyre size, at rear

mm

Ø 400 x 160

3.5

Wheels, number front/rear (× = driven wheels)

2 / 1x

Basic dimensions

4.2

Mast height (lowered)

h

1

mm

3820

3920

3820

3920

4.4

Lift

h

3

mm

5500

4.5

Extended mast height

h

4

mm

6650

6750

6650

6750

4.7

Height of overhead guard

h

6

mm

2461

4.8

Seat height/stand height

h

7

mm

1360

4.19.2

total length (without load)

mm

3492

3780

3425

3711

4.20

Length incl. back of forks

l

2

mm

3176

3475

4.21

Total width

b

1

/b

2

mm

1210 / 1450

1210 / 1450

1210 / 1210

1210 / 1250

4.22

Fork dimensions

s/e/l mm

40 / 120 /

1200

50 / 120 /

1200

60 / 180 /

1200

60 / 180 /

1200

4.23

Fork carriage ISO 2328, class/type A, B

2A

2A

4.24

Fork carriage width

b

3

mm

880

880

4.25

Width over forks

b

5

mm

845

845

540

540

4.29

reach, sideways

mm

1290

1290

1300

1300

4.31

Floor clearance with load under mast

m

1

mm

80

4.32

Floor clearance centre wheelbase

m

2

mm

85

4.33.16

Working aisle width for 1200 x 800 pallet

Ast mm

1600

1600

1400

1450

4.35

Turning radius

W

a

mm

2135

2460

2135

2460

4.38.4

pallet width

mm

800

4.38.5

pallet length

mm

1200

4.38.7

inner clear height of operator compartment

mm

1518

Performance da

ta

5.1

Travel speed, w. / w.o. load

km/h

10.5 / 10.5

5.2

Lift speed, w. / w.o. load

m/s

0.45 / 0.46

0.45 / 0.46

2)

0.45 / 0.46

0.45 / 0.46

2)

5.3

Lower speed, w. / w.o. load

m/s

0.48 / 0.48

5.4

Traverse speed w. / w.o. load

m/s

0.3 / 0.3

3)

5.10

Service brake

generated

5.11

Parking brake

electric spring-loaded

Electrics

6.1

Drive motor rating S2 60 min.

kW

7.6

6.2

Lift motor rating at S3 25%

kW

21.0

6.3

Battery according to DIN 43531/35/36 A,B,C, no

3 PzS 465

5 PzS 775

3 PzS 465

5 PzS 775

6.4

Battery voltage/nominal capacity K5

V/Ah

80 / 465

80 / 775

80 / 465

80 / 775

6.5

Battery weight

kg

1238

1863

1238

1863

Misc.

8.1

Type of drive control

AC Control

8.4

Sound pressure level at operator’s ear according to EN
12053

dB (A)

65

8.6

Steering

electric
