LED Indicators
This chapter explains how to interpret the front-panel LED indicators
on the FriendlyNet Fast Ethernet Switch.
The indicators are discussed in the following sections.
❏ LED indicators on the Switch
❏ LED indicators for power connections
❏ LED indicators for port connections
❏ LED indicators for Switch connections
LED Indicators on the Switch
The LED indicators on the Switch are used to facilitate monitoring and
troubleshooting.
These LEDs are:
❏ Power
❏ Link/Act (Link/Activity)
❏ 100 Mbps Operation
❏ FDX/Col (Full-duplex/Collision)
