Components
Page 2-3
FS4008DS
The front panel of the FS4008DS consists of eight 10/100 Mbps ports,
one Uplink port, and LED indicators. See Figure 2-3.
Figure 2-3 FriendlyNet FS4008DS front panel
The back panel of the FS4008DS consists of a power switch, an AC
power connector, and a system fan.
Figure 2-4 FriendlyNet FS4008DS back panel
1 2 3 4 5 6 7 8 Uplink or 100Mbps
Link/Act
FDX / Col
Power
FS4008DS FriendlyNet
8-port Dual Speed Ethernet Switch
1 2 3 4 5 6 7 8
Switched 10/100Mbps Ports
Uplink Port
LEDs Eight 10/100 Ports
System Fan Power Switch
AC Power Connector
