ApplianceLinc Owner’s Manual
Page 5 of 14
INSTALLATION
Preparing to Install ApplianceLinc
CAUTION
Read and understand these instructions before installing and retain them for future reference.
ApplianceLinc is intended for installation in accordance with the National Electric Code and local
regulations in the United States or the Canadian Electrical Code and local regulations in Canada. Use
indoors only. ApplianceLinc is not designed nor approved for use on power lines other than 120V 60Hz,
single phase. Attempting to use ApplianceLinc on non-approved power lines may have hazardous
consequences.
Prior to installing ApplianceLinc, please review the entire installation procedure and take the following
precautions:
• Don’t plug ApplianceLinc into an outlet controlled by a switch because if the switch is
inadvertently turned off, ApplianceLinc won’t have power
• Don’t plug ApplianceLinc into a filtered power strip or AC line filter
• Be sure the device’s built-in switch is in the on position
• Be sure ApplianceLinc is connected to a 3-prong AC outlet that includes a Ground Fault Circuit
Interrupt (GFCI) feature. If ApplianceLinc is plugged into an outlet without GFCI protection, make
sure there is a GFCI device upstream (at another outlet closer to the electrical panel or a GFCI
circuit breaker).
• Test your GFCI protection each time ApplianceLinc is plugged in, as well as on a monthly basis.
To test your GFCI protection, make sure ApplianceLinc is plugged in and the connected load is
on. Then, push the TEST button on the GFCI outlet or circuit breaker. This unit must stop
operating. Wait about 5 seconds and then push the RESET button on the GFCI outlet or circuit
breaker. ApplianceLinc will begin receiving electricity and the connected load will turn on. If the
GFCI circuit does not perform in this manner, there may be an electrical malfunction, increasing
the probability of electric shock. Disconnect the power until the problem has been corrected.
Please see the instructions that came with your GFCI device for specific testing procedures.
When in doubt of the GFCI device’s ability to detect a ground fault, replace the GFCI device.
• Don’t bury ApplianceLinc, any electrical cable, or component connected to it. A buried power cord
may result in electrocution if improper cables are used or if digging occurs over the cable.
• Don’t allow vegetation to grow on or around ApplianceLinc
• Don’t install ApplianceLinc in a manner that allows water to accumulate around it
• Don’t exceed the load rating of ApplianceLinc. Check and add up all the electrical devices that will
be attached and make sure the total does not exceed 15 Amps.
• Don’t use any electrical cord or extension cord that is damaged or in poor condition
• If an extension cord is used, the cord must be properly grounded. Be sure the extension cord is of
adequate capacity to provide power to your load. A “light-duty” or “medium-duty” extension cord
may cause a voltage drop, which will cause overheating of the cable, plug, or socket.
• Don’t attempt to open ApplianceLinc. The case is sealed and can’t be opened. There are no user-
serviceable parts inside.
• Don’t use ApplianceLinc to control devices that preserve, maintain, or contribute to human or
animal safety or life support
If you have any questions, please call:
INSTEON Gold Support Line
800-762-7845
