Error Blink
Default = on. This setting is adjustable via software or a central controller only. SwitchLinc LED blinks for
a few seconds if one or more responders do not acknowledge a message.
Specifications
General
Product name SwitchLinc Dimmer High Wattage
Brand INSTEON
Manufacturer product number 2477DHxx
UPC
White – 2477DHWH: 813922011005
Almond – 2477DHAL
Ivory – 2477DHIV
Warranty 2 years, limited
INSTEON
INSTEON powerline mesh repeater Yes
INSTEON RF mesh repeater Yes
INSTEON controller Yes
INSTEON responder Yes
Maximum links/scenes 400
Load brightness levels 32 (256 when controlled by software)
Brightness of LEDs Adjustable, from off to 100% bright
Local on-level 4 locally, increments of 1% with software
Local ramp-rate 0.1 seconds to 2 seconds (0.125 seconds to 8 minutes via software)
Local control Yes
Commands supported as controller
On Off
Fast on Fast off
Brighten Dim
Commands supported as responder
On Off
Fast on Fast off
Brighten Dim
Software configurable Yes
RF range Up to 150’ open air
Phase bridge detect beacon Yes
INSTEON device category
0x01 dimmable lighting control (all frequencies)
INSTEON device subcategory
0x01 0x20
X10
X10 address 1 optional (comes unassigned)
X10 transmitter Yes
X10 receiver Yes
