17
Installation
3.2 Installation guidelines
WARNING
Explosion hazard. This product is not designed for hazardous
locations where combustible environments may exist.
Refer to the following guidelines and Figure 6 when evaluating
site location.
• If the site is located in a confined space such as a manhole,
refer to
section 2.1.3 on page 12 for safety information.
• Make sure that the site has a level surface or a place to hang
the suspension harness, support bracket or spanner bar
(
Figure 6 ).
Figure 5 Sampler with multiple bottles
1 Sampler base 7 Intake tubing, vinyl or teflon-lined
2 Sample bottles 8 Strainer
3 Retainer 9 Distributor assembly
4 Sampler center section 10 AC power supply (optional)
5 Battery (Cat. No. 8754400, optional) 11 Battery recharger (optional)
6 Top cover (Cat. No. 8890)
