6
Specifications
1.1 Dimensions
Figure 1 Sensor without and with cleaning unit
1 Sensor without cleaning unit 2 Sensor with cleaning unit
Environment considerations
Sample temperature 1 to 40 °C (34 to 104 °F)
Ambient temperature
–5 to +45 °C (23 to 113 °F) 
Measurement sensor wetted by at least half from the measuring
medium:

–25 to +55 °C (-13 to 131 °F)
Sensor distance - wall/ground min. 100 mm (3.94 in.) (recommended)
Miscellaneous
Cable length 1.5 or 10 m, extension cable up to total maximum length of 40 m
Connection
information
Sensor side 8-pin, type of protection IP68, PUR
Controller side M12, type of protection IP67
Inspection interval
Every 2 years; 1/year service agreement by request, with warranty
extension up to 5 years
Maintenance requirements
Clean the measurement window, if necessary. Intervals are dependent
on the measuring medium.
Compliance CE
Warranty 2 years
