Overview of configuration steps
PH/ORP
PH
(GLAS EL/FEt EL )
GLAS EL
0-20 mA/4-20 mA
4-20 mA
xxxx
00.00 pH
xxxx
14.00 pH
Time averaging filter
xxxx SEC
0 SEC
22 mA signal in the case of error
ON / OFF
OFF
Signal response during HOLD
Last / Fix
Last
Enter fixed value
xxx.x mA
021.0 mA
out2
Output 2
o2.
Select temperature unit
°C / °F
°C
Select temperature probe
100 Pt/1000 Pt/30NTC/
8.55NTC/3000B
1000 Pt
Select current range
0-20 mA/4-20 mA
4-20 mA
Enter current start
xxx.x
000.0 °C
Enter current end
xxx.x
0100.0 °C
Time averaging filter
0000 ... 0120 SEC)
0 SEC
22 mA signal for temp error
ON / OFF
OFF
Signal
response during HOLD
Last / Fix
Last
Enter fixed value
xxx.x mA
021.0 mA
tc.
Temperature compensation
tc.
Temp detection during meas
Auto/man (man: xxx.x °C)
Temp detection during cal
Auto/man (man: xxx.x °C)
Enter TC process medium
xx.xx %/K
00.00%/K
CAL
Calibration mode
CA.
Select calibration mode
BUF/MAN/DAT
06 BUF
Enter cal timer interval
xxxx h
0000 h
Menu
Code
out1
Output 1
o1.
Select process variable
Select electrode type
Select current range
Enter current start
Enter current end
