35
Installation
7. Repeat steps to add additional probes/devices and tags.
8. Press the ENTER button to save the configuration.
Table 1 Telegram list—Column description
Column Description
1
Data position in the configured Profibus slave (in 2 byte words)
Modbus: Data position in the configured Modbus slave
This slave contains holding registers beginning at 40001.
Example: "0" means register 40001 and "11" means register 40012.
2 Tag name to identify the configured data.
3
Data type
float=floating point value
int=integer values
sel=integer value resulting from an enumeration or selection list
4
Data status
r=data is read only
r/w=read/write
Table 2 Error register
Bit Error Description
0 Calibration error Faulty calibration detected
1 Electronic settings error Faulty electronic calibration/settings
2 Cleaning error Error in cleaning cycle detected
3 Measuring module error Error in measuring module detected
4 System initialization
Inconsistent settings detected, reset to factory
settings
5 Hardware error Faulty hardware detected
6 Internal communication error Internal communication error detected
7 Humidity error Excessive humidity detected
8 Excessive temperature Excessive temperature detected
9
10
Sample feed warning Error in sample feed detected
11 Questionable calibration warning Accuracy of previous calibration inadequate
12
Questionable measurement
warning Accuracy of previous measurement inadequate/out of
range
13 Safety warning Safety equipment error detected
14 Reagent warning Reagent warning, e.g. fill level < min detected
15 Service request warning Service request detected
