When a new user (or a new Card)
is added, if you decided not to
modify the
Entry Type suggested
by Rbm21 (see SYSTEM
CONFIGURATION ), you must enable
the Card to activate relay 1 or
relay 2.
You may also select both, for
example if automation is
connected to one outlet and
lights to another.
If the Double Entry Type is
chosen instead, the Output area
will not be active.
Outputs
2 1
