6.3 Electrical connections
230 V (a.c.) power supply
230V output in motion (e.g. fl ashing light 25W)
24V powering accessories max. 40W
Pushbutton stop (N.C.)
Pushbutton partial opening (N.O.)
Pushbutton for controlled (see dip-switch 2-3)
Contact (N.C.) for «re-aperture during closure»
Pushbutton open (N.O.)
Contact (N.C.) for «partial stop»
Connection limit switch opens
Connection limit switch closes
Antenna connection
5 6 7 % , . 43 0 # # %" %" &# &! &
(Condenser)
U
W
V
230 V (a.c.) motor M
EB
EB
Output supplied for electric lock
N.B. Maintain polarity when connecting photoelectric cells (DIR)
48 48 # .#
48 28
2
4
Pushbutton close (N.O.)
