Service Assemblies
Brine Line Flow Controls (9000/9100):
.
60022-12...................
BLFC, .125 GPM, 5000/5600/9000/9100
.
60022-25...................
BLFC, .25 GPM, 5000/5600/9000/9100
.
60022-50...................
BLFC, .50 GPM, 5000/5600/9000/9100
.
60022-100.................
BLFC, 1.0 GPM, 5000/5600/9000/9100
.
60350........................
Brine Valve Assy, 9000/9100
Brine Line Flow Controls (9500):
.
60020-25...................
BLFC, .25 GPM, 1600
.
60020-50...................
BLFC, .50 GPM, 1600
.
60020-100.................
BLFC, 1.0 GPM, 1600
Brine Valve Assemblies:
.
60037-610.................
Brine Valve, 9500/1600, .25 GPM,
Cold & HW 180°
.
60037-620.................
Brine Valve, 9500/1600, .50 GPM,
Cold & HW 180°
.
60037-630.................
Brine Valve, 9500/1600, 1.0 GPM,
Cold & HW 180°
.
60350........................
Brine Valve Assy 9000/9100,
Cold & HW 180°
.
60350-01...................
Brine Valve Assy, 9000/9100/Twinfl100,
Cold & HW 180°
1700 Brine Valve Assembies (9500):
.
60039-XX..................
Brine Valve, 1700/9500, Cold & HW 180°
Bypass Assemblies:
.
60040SS....................
Bypass Valve, 5600, 3/4” NPT
.
60041SS....................
Bypass Valve, 5600, 1” NPT
.
60049........................
Bypass Plastic Assy
Injector Assemblies (9000/9100):
.
60385-X.....................
Injector Assembly (specify size of injector)
Injector
Number
DLFC
Number
BLFC
Number
Red #0......... 00............... Blank...... 0.................Blank...... 0
White #1...... 01............... 1.2.......... 1.................0.25........ 1
Blue #2 ....... 02............... 1.5.......... 2.................0.50........ 2
Yellow #3 .... 03............... 2.0.......... 3.................1.00........ 3
Green #4..... 04............... 2.4.......... 4.
.
.
3.0.......... 5.
.
.
.
3.5.......... 6.
.
.
.
4.0.......... 7.
.
.
.
5.0.......... 8.
.
.
.
7.0.......... 9
Injector Assemblies (9500):
.
60381-03...................
Injector Assy, 1700, #3, Cold & HW 150°
.
60381-04...................
Injector Assy, 1700, #4, Cold & HW 150°
.
60381-05...................
Injector Assy, 1700, #5, Cold & HW 150°
.
60381-06...................
Injector Assy, 1700, #6, Cold & HW 150°
.
60480-01...................
Injector Assy, 1600, #1, Plastic,
Cold Water
.
60480-02...................
Injector Assy, 1600, #2, Plastic,
Cold Water
.
60480-03...................
Injector Assy, 1600, #3, Plastic,
Cold Water
.
60480-04...................
Injector Assy, 1600, #4, Plastic,
Cold Water
.
60481-21...................
Injector Assy, 1600, #1, SS, HW 180°
.
60481-21...................
Injector Assy, 1600, #2, SS, HW 180°
.
60481-21...................
Injector Assy, 1600, #3, SS, HW 180°
.
60481-21...................
Injector Assy, 1600, #4, SS, HW 180°
Meter Assemblies (9000/9100):
.
15078-01...................
Adapter, 1” Coupling
.
60086........................
Meter Assy, 5600/9000/9100,
3/4” Std/Range
.
60087........................
Meter Assy, 5600/9000/9100, 3/4”, Ext
.
60389........................
Meter Assy, 9000/9100, 1”
60389NP................... Meter Assy, 9000/9100, 1”, N/P
.
60389-20...................
Meter Assy, 9000/9100, 1”, BSP/Metric
.
60390........................
Meter Assy, 9000/9100, 1”, Ext
60390NP................... Meter Assy, 9000/9100, 1”, Ext, N/P
.
60390-20...................
Meter Assy, 9000/9100, 1”, Ext/BSP/Metric
.
60612........................
Meter Assy, 9000/9100, 1”, Std Range,
HW 150°
60612NP................... Meter Assy, 9000/9100, 1”, Std Range,
HW 150°, NP
.
14038........................
Meter Cap Assy
.
15150........................
Meter Cap Assy, Ext
.
15218........................
Meter Cap Assy
15218NP................... Meter Cap Assy, Std, NP
.
15237........................
Meter Cap Assy, Ext
15237NP................... Meter Cap Assy, Ext, NP
.
13509........................
Impeller, Meter
.
13509-01...................
Impeller, Celcon, HW 150°
Meter Assemblies (9500):
.
60610-01...................
Meter, 2850/9500, 1 1/2” Std
60610-01HW............. Meter, 2850/9500, 1 1/2” Std, HW 150°
60610-01NP.............. Meter, 2850/9500, 1 - 1/2” Std, N/P
.
60610-02...................
Meter, 2850/9500, 1 - 1/2” Ext
60610-02HW............. Meter, 2850/9500, 1 1/2” Ext, HW 150°
60610-02NP.............. Meter, 2850/9500, 1 - 1/2” Ext, N/P
.
60610-21...................
Meter, 2850/9500, 1 - 1/2” Std/BSP Metric
60610-21NP.............. Meter, 2850/9500, 1 - 1/2” Std/BSP
Metric, Nickel Plated
.
60610-22...................
Meter, 2850/9500, 1 - 1/2” Ext/BSP Metric
60610-22NP.............. Meter, 2850/9500, 1 - 1/2” Ext/BSP
Metric/Nickel Plated
60611-01HW............. Meter, 2850/9500, 1” Sleeve,
1 1/2” Std, HW 150°
.
60611-01...................
Meter, 2850/9500, 1” Sleeve,
1 1/2” Std Meter
60611-01NP............... Meter, 2850/9500, 1” Sleeve, NP
1 1/2” Std Meter
.
60611-02...................
Meter, 2850/9500, 1” Sleeve,
1 1/2” Ext Meter
60611-02NP............... Meter, 2850/9500, 1” Sleeve, NP 1 1/2”
Ext Meter
.
17790........................
Sleeve, Meter, 1 1/2” x 1” (NOTE: when
reducing a 1-1/2” meter to a 1” meter,
the program wheel and timer settings must
be changed to a 1” meter size)
