Job Specification Sheet
Job Number: __________________
Model Number: ________________
Water Test: ___________________
Capacity Per Unit: ______________
Mineral Tank Size: ___________ Diameter: ___________ Height: __________
Brine Tank Size & Salt Setting per Regeneration: __________
9000/9100/9500 Control Valve Specifications:
.
1... Type of Timer:
A. 82 minute available regeneration time, 1/15 RPM
B. 164 minute available regeneration time, 1/30 RPM
.
2.. Type of Meter:
Mechanical Valves (Gallon Settings)
Meter
Standard Range
Extended Range
3/4”
125 - 2,125
625 - 10,625
1”
310 - 5,270
1,150 - 26,350
1-1/2”
625 - 10,625
3,125 - 53,125
3. Timer Gallon Setting: _______________ Gallons
.
4. Regeneration Program Setting:
A. Backwash: ____________________ Minutes
B. Brine and Slow Rinse: ___________ Minutes
.
C. Rapid Rinse: __________________ Minutes
.
D. Brine Tank Refill: _______________ Minutes
5. Drain Line Flow Control: ____________ gpm
6. Brine Refill Rate: __________________ gpm
7. Injector Size: _____________________
